S1600 Pro Single-Pass High-Speed Corrugated Board Digital Printer
Utilizing plateless inkjet printing technology, the S1600 Pro can be equipped with up to 48 Epson i3200 piezoelectric high-precision printheads or industrial printheads. With multiple configuration options, it achieves exceptional precision for fine text, high saturation for large color blocks, and versatile digital printing modes. With a printing width ranging from 500mm to 1500mm, it can be customized based on order structures, making it the ultimate choice for high-volume digital production.
Key Features
✅ 1500mm Printing Width: Supports a variable printing width of 500–1500mm, customizable based on specific order structures.
✅ 24/32/48 Printhead Configurations: Delivers up to 1200dpi resolution for fine, rich, and vibrant colors.
✅ High-Speed Productivity: Direct output speed of 50–80 meters/minute.
✅ Industrial-Grade Heavy-Duty Automatic Paper Feeding System: Features servo-controlled rear baffles to ensure stable output for long and heavy corrugated boards without jamming or scratching. The platform roller design ensures smoother paper feeding.
✅ Fully Automatic Front-Edge Feeding System: Controlled entirely by servo motors for highly accurate paper feeding, automatic positioning, and enhanced efficiency. It offers superior compatibility and easily handles materials of varying thicknesses.
✅ High-Precision Industrial Control & Linear Motors: The Y-axis utilizes a high-torque servo motor and a high-precision planetary reducer for more accurate, faster, and stable stepping. The high-precision X-axis linear motor provides optimal control for the printhead carriage, ensuring precision and durability.
✅ Automatic Negative Pressure Ink Supply System: Maintains constant ink supply momentum for a smoother flow. With negative pressure precision controlled within 0.02kPa, ink droplets remain uniform and stable for finer printing, significantly reducing consumable and labor waste.
✅ Fully Automatic Precision Paper Feeding: Achieves ultra-high control precision of ±0.1mm, ensuring paper feeds straight without deviation or jamming.
✅ Smart Vacuum Printing Platform: Compatible with corrugated boards of all thicknesses, completely solving issues with warped or skewed paper.
✅ Stable Negative Pressure Control: Precise pressure control at 0.02kPa saves consumables while delivering exquisite print quality.
Core Specifications
- Model: S1600 Pro
- Printheads: 24H / 32H / 48H Epson i3200 High-Precision Printheads / Customized Epson Industrial Printheads
- Printing Width: 1500mm
- Max Resolution: 1200dpi
- Speed: 50–80m/min
- Media Thickness Compatibility: 0–50mm
- Ink Type: Water-Based Dye Ink / Water-Based Pigment Ink
- Ink Colors: Standard CMYK (White ink optional)
- Paper Feeding Method: Fully Automatic Front-Edge Feeding
Application Scenarios
- Premium Color Cartons: High-definition, full-bleed large-format printing, gift packaging, and customized brand cartons.
- Standard Courier Packaging: Ultra-high-speed mass production of standard cartons.
- Multi-Specification & Full-Size Packaging: One-stop printing for corrugated boards of all sizes and thicknesses.
- Flexible Order Production: Comprehensive coverage for small-batch custom proofs and large-scale mass production.
